Examples
Contents
Examples¶
Nginx gateway, services routing based on the path¶
https://github.com/husio/lith/tree/master/examples/nginx_gateway/
First, make sure to run make docker-image
in the projects main directory. This will build a docker image called lith
.
Run docker-compose up
to start the application. You can use -d
flag to run it in the background.
% docker-compose up
Starting nginx_gateway_lith-admin_1 ... done
Starting nginx_gateway_mailhog_1 ... done
Starting nginx_gateway_app_1 ... done
Starting nginx_gateway_lith_1 ... done
Starting nginx_gateway_gateway_1 ... done
Attaching to nginx_gateway_lith-admin_1, nginx_gateway_mailhog_1, nginx_gateway_app_1, nginx_gateway_lith_1, nginx_gateway_gateway_1
gateway_1 | /docker-entrypoint.sh: /docker-entrypoint.d/ is not empty, will attempt to perform configuration
gateway_1 | /docker-entrypoint.sh: Looking for shell scripts in /docker-entrypoint.d/
gateway_1 | /docker-entrypoint.sh: Launching /docker-entrypoint.d/10-listen-on-ipv6-by-default.sh
mailhog_1 | 2021/12/05 09:23:34 Using in-memory storage
gateway_1 | 10-listen-on-ipv6-by-default.sh: error: IPv6 listen already enabled
nginx_gateway_lith-admin_1 exited with code 0
mailhog_1 | 2021/12/05 09:23:34 [SMTP] Binding to address: 0.0.0.0:1025
gateway_1 | /docker-entrypoint.sh: Launching /docker-entrypoint.d/20-envsubst-on-templates.sh
mailhog_1 | [HTTP] Binding to address: 0.0.0.0:8025
gateway_1 | /docker-entrypoint.sh: Configuration complete; ready for start up
mailhog_1 | 2021/12/05 09:23:34 Serving under http://0.0.0.0:8025/
mailhog_1 | Creating API v1 with WebPath:
mailhog_1 | Creating API v2 with WebPath:
When successful, several services will be running.
Nginx is running on port 8000 and serving all the traffic.
A Python web application is running and you can access it via Nginx. This is where your business logic would be.
A Lith instance is running and you can access it via Nginx. Several endpoints are available:
Authentication at http://localhost:8000/auth/login/
Admin panel at http://localhost:8000/admin/
A Mailhog test SMTP server with web a UI running at http://localhost:8025.
During startup an admin account admin@example.com
with password admin
is created. You can use it to login.
For convenience, two-factor authentication is disabled. You can enable it in the lith.conf
by setting RequireTwoFactorAuth = true
. Enabling two-factor authentication can be done at any time - existing accounts will be requested to update during authentication.
% docker-compose ps
Name Command State Ports
-------------------------------------------------------------------------------------------------------------------------
nginx_gateway_app_1 python main.py Up
nginx_gateway_gateway_1 /docker-entrypoint.sh ngin ... Up 0.0.0.0:8000->80/tcp,:::8000->80/tcp
nginx_gateway_lith-admin_1 /bin/lith -conf /etc/lith. ... Exit 1
nginx_gateway_lith_1 /bin/lith -conf /etc/lith. ... Up
nginx_gateway_mailhog_1 MailHog Up 1025/tcp, 0.0.0.0:8025->8025/tcp,:::8025->8025/tcp
How it works.¶
When you go to http://localhost:8000, Python application will check if you have an active session by introspecting your cookies. If you provide a session cookie, a call to Lith is made to validate and introspect your token. If you are not authenticated, Python application will display a link to Lith authentication page where you can authenticate.
A standalone Go application with an embedded reverse proxy to Lith¶
https://github.com/husio/lith/tree/master/examples/go_reverseproxy/
First, make sure to run make docker-image
in the projects main directory. This will build a docker image called lith
.
Run docker-compose up
to start the application. You can use -d
flag to run it in the background.
% docker-compose up
Starting go_reverseproxy_mailhog_1 ... done
Starting go_reverseproxy_app_1 ... done
Starting go_reverseproxy_lith-admin_1 ... done
Starting go_reverseproxy_lith_1 ... done
Attaching to go_reverseproxy_mailhog_1, go_reverseproxy_lith-admin_1, go_reverseproxy_app_1, go_reverseproxy_lith_1
app_1 | running on 0.0.0.0:8000
mailhog_1 | 2021/12/09 08:49:49 Using in-memory storage
mailhog_1 | 2021/12/09 08:49:49 [SMTP] Binding to address: 0.0.0.0:1025
mailhog_1 | [HTTP] Binding to address: 0.0.0.0:8025
go_reverseproxy_lith-admin_1 exited with code 0
mailhog_1 | 2021/12/09 08:49:49 Serving under http://0.0.0.0:8025/
mailhog_1 | Creating API v1 with WebPath:
mailhog_1 | Creating API v2 with WebPath:
When successful, several services will be running.
A Go application running on http://localhost:8000 All requests prefixed with
/account/
path are being proxied to Lith.A Lith instance is running. Only admin panel is publicly available at http://localhost:8003/admin/
A Mailhog test SMTP server with a web UI running at http://localhost:8025.
During startup an admin account admin@example.com
with password admin
is created. You can use it to login.
For convenience, two-factor authentication is disabled. You can enable it in the lith.conf
by setting RequireTwoFactorAuth = true
. Enabling two-factor authentication can be done at any time - existing accounts will be requested to update during authentication.
% docker-compose ps
Name Command State Ports
---------------------------------------------------------------------------------------------------------------------------
go_reverseproxy_app_1 ./app Up 0.0.0.0:8000->8000/tcp,:::8000->8000/tcp
go_reverseproxy_lith-admin_1 /bin/lith -conf /etc/lith. ... Exit 0
go_reverseproxy_lith_1 /bin/lith -conf /etc/lith. ... Up 0.0.0.0:8003->8003/tcp,:::8003->8003/tcp
go_reverseproxy_mailhog_1 MailHog Up 1025/tcp, 0.0.0.0:8025->8025/tcp,:::8025->8025/tcp
How it works.¶
When you go to http://localhost:8000, Go application will check if you have an active session by introspecting your cookies. If you provide a session cookie, a call to Lith is made to validate and introspect your token. If you are not authenticated, Go application will display a link to Lith authentication page where you can authenticate. All requests to Lith are proxied by Go application. End user cannot notice that authentication is done by a separate application.
A single page application using Lith JSON API¶
https://github.com/husio/lith/tree/master/examples/js_spa/
First, make sure to run make docker-image
in the projects main directory. This will build a docker image called lith
.
Run docker-compose up
to start the application. You can use -d
flag to run it in the background.
% docker-compose up
Starting js_spa_lith-admin_1 ... done
Starting js_spa_mailhog_1 ... done
Starting js_spa_lith_1 ... done
Starting js_spa_frontend_1 ... done
Attaching to js_spa_lith-admin_1, js_spa_mailhog_1, js_spa_lith_1, js_spa_frontend_1
frontend_1 | /docker-entrypoint.sh: /docker-entrypoint.d/ is not empty, will attempt to perform configuration
frontend_1 | /docker-entrypoint.sh: Looking for shell scripts in /docker-entrypoint.d/
mailhog_1 | [HTTP] Binding to address: 0.0.0.0:8025
frontend_1 | /docker-entrypoint.sh: Launching /docker-entrypoint.d/10-listen-on-ipv6-by-default.sh
js_spa_lith-admin_1 exited with code 0
frontend_1 | 10-listen-on-ipv6-by-default.sh: error: IPv6 listen already enabled
mailhog_1 | 2021/12/09 09:42:33 Using in-memory storage
mailhog_1 | 2021/12/09 09:42:33 [SMTP] Binding to address: 0.0.0.0:1025
mailhog_1 | 2021/12/09 09:42:33 Serving under http://0.0.0.0:8025/
frontend_1 | /docker-entrypoint.sh: Launching /docker-entrypoint.d/20-envsubst-on-templates.sh
frontend_1 | /docker-entrypoint.sh: Configuration complete; ready for start up
mailhog_1 | Creating API v1 with WebPath:
mailhog_1 | Creating API v2 with WebPath:
When successful, several services will be running.
Nginx is running on port 8000 and serving all the traffic.
A JavaScript Single Page Application is running and you can access it via Nginx. This is where your business logic would be.
A Lith instance is running and you can access it via Nginx. Admin panel at http://localhost:8000/admin/
A Mailhog test SMTP server with web a UI running at http://localhost:8025.
During startup an admin account admin@example.com
with password admin
is created. You can use it to login.
For convenience, two-factor authentication is disabled. You can enable it in the lith.conf
by setting RequireTwoFactorAuth = true
. Enabling two-factor authentication can be done at any time - existing accounts will be requested to update during authentication.
% docker-compose ps
Name Command State Ports
------------------------------------------------------------------------------------------------------------------
js_spa_frontend_1 /docker-entrypoint.sh ngin ... Up 0.0.0.0:8000->80/tcp,:::8000->80/tcp
js_spa_lith-admin_1 /bin/lith -conf /etc/lith. ... Exit 0
js_spa_lith_1 /bin/lith -conf /etc/lith. ... Up
js_spa_mailhog_1 MailHog Up 1025/tcp, 0.0.0.0:8025->8025/tcp,:::8025->8025/tcp
How it works.¶
When you go to http://localhost:8000, Nginx serves Single Page Application. JavaScript application will communicate with Lith in order to authenticate and manage your identity. All calls to Lith are done using JSON API.
